🛠️ 3rd Gen Audi LED Emblem Installation Guide for Q8 e-tron (2022-UP)

🛠️ 3rd Gen Audi LED Emblem Installation Guide for Q8 e-tron (2022-UP)

About the Black Controller (Voltage Regulator)

Inside your LED emblem kit you’ll find a small black box — this is the voltage regulator, and it connects in-line between your car’s power and the emblem.

Here’s why it matters: your car’s power supply isn’t a steady 12V. When the engine is running, the voltage often rises above 12V. The black controller regulates the power and keeps it steady at 12V, protecting your emblem from voltage spikes.

The LED emblem will still light up without it, but we strongly recommend connecting the black controller — it keeps the power stable and helps your emblem last longer.

How to connect: wire the black controller in-line between your power source and the emblem (power → black controller → emblem). Message us on WhatsApp if you’d like help with the wiring.



Applicable Models: Audi Q8 e-tron (2022–UP) & Q4 e-tron (2022–UP)

Note: The physical emblem mounting process is exactly the same for both the Q4 e-tron and Q8 e-tron. Please follow the standard 3rd Gen Audi LED Emblem instruction guide for mounting, and use the specific wiring steps below to get power for your Q8 e-tron.

Are there any Adaptive Cruise Control (ACC) or radar components positioned behind the emblem area on the Q8 e-tron (2022–UP)?

There is no Adaptive Cruise Control (ACC) or radar sensor located directly behind the emblem on the Audi Q8 e-tron (2022–UP).

When installing the LED emblem, we highly suggest securing and tucking the wiring neatly so that it does not block or obstruct the center round camera/sensor bulb.

⚡ Q8 e-tron Fuse Box Power Connection

Based on successful installation feedback shared by our customers, here is the best way to wire the emblem using the fuse box:

  • Locate the Thermal System Slots: Look at the bottom of the provided diagram/pictures. Locate the three slots dedicated to the vehicle's thermal management system.
  • Connect the Fuse Plug: Plug the included 7.5A fuse box adapter into one of these three thermal system slots.

💡 How the Emblem Will Function:

Connecting to this specific fuse slot configures the emblem to sync perfectly with your car key commands:

  • When Starting: When you unlock, remote start, or turn on the ignition, the LED emblem will automatically power up, flash 3 times, and then stay cleanly illuminated.
  • When Turning Off: When you turn off the vehicle or lock it, the emblem will shut down.
  • Note on Delayed Shut-off: The emblem will not turn off instantly. Because the thermal system holds residual power for a short period, the emblem will stay lit for a few minutes until the vehicle's electrical system completely goes to sleep.
