How to Install Audi LED Glowing Rear Emblem (Step-by-Step Guide)

How to Install Audi LED Glowing Rear Emblem (Step-by-Step Guide)

🛠️ LED Emblem Installation Guide

00:00 – Remove the Original Emblem Gently remove your factory emblem.

Pro Tip: Using fishing line to "saw" through the adhesive is the safest way to avoid scratching your paint.

00:19 – Clean the Surface Thoroughly remove any leftover adhesive or residue from the original emblem area.

00:20 – Access the Power Source Locate and unplug the factory license plate light connector.

00:25 – Routing the Wires Carefully drill a small pilot hole (if required) to pass the emblem wiring through to the interior of the trunk/hatch.

00:32 – Apply Adhesion Promoter Use the adhesion promoter included in your package to clean the installation area one last time. This ensures a permanent bond.

00:43 – Mount the LED Emblem Peel off the 3M adhesive backing from the LED emblem and press it directly onto the cleaned surface.

00:59 – Secure the Bond Apply firm, even pressure across the entire emblem for 20–30 seconds to ensure it is securely attached.

01:10 – Connect the Harness Pull the emblem’s wire harness through the license plate light opening.

01:18 – Connect the Control Box Plug the emblem’s connector into the black control box connector.

01:20 – Secure the Control Box Use double-sided tape to fix the black control box securely inside the license plate light housing area.

01:56 – Final Wiring Connect one end of the control box harness to the license plate light harness provided in your package.

02:08 – Plug & Play Connection Connect one plug to the emblem and the other to the factory license plate light you previously unplugged.

02:19 – Installation Complete Test the light by turning on your vehicle's parking lights. Enjoy your new LED emblem!

🔧 TOOLS NEEDED:

• Fishing line (for emblem removal)
• Microfiber cloth & Cleaning solution
• Small drill (for wire routing)

We have included a custom license plate light harness in your package for a true 'Plug & Play' installation. This allows you to connect the emblem without cutting or splicing any of your vehicle's original wiring. If you have any questions during the process, please feel free to reach out—we are here to help!
